M1400
14-inch Rugged Laptop (IP65)
● Intel Core i5-8250U / i7-8550U
● 8GB DDR4L+128GB SSD
● 1920*1080 IPS
● 700nit high brightness display
● Corning Gorilla Glass TP
● Windows10 (support Windows7)
● 2000mah built-in battery+6300mah External hot-plug battery
● WIFI 2.4G+5Ghz
● 4G LTE
● GPS
● IP65
● Working temperature: -10℃ to 50℃
TECH SPECS
|
Model No. |
M1400 |
|
Screen size |
14 inch |
| Resolution | 1920*1080 IPS |
| Ratio | 16:9 |
|
IP Level |
IP65 |
| Drop-Proof | 100 cm Wood floor |
|
OS |
Windows 10 Home / Windows 7 |
|
CPU |
Intel® Core™ i5-8250U |
|
Quad-core, 1.60 GHz~3.40 GHz |
|
|
RAM |
8GB LPDDR4 |
|
ROM |
256GB / 512GB SSD |
|
Support external HDD 500GB |
|
|
Resolution |
1920*1080 IPS |
|
Touch |
10-Point Touch G+G |
|
Camera |
2.0 MP Front Camera |
|
Wifi |
WIFI 802.11(a/b/g/n/ac) 2.4G+5.8G |
|
蓝牙 |
BT4.2 (BLE) (Distance: 10 meters) |
|
3G/4G |
LTE FDD: B1/B3/B5/B7/B8/B20/B28A |
|
LTE TDD: B38/B40/B41 |
|
|
WCDMA: B1/B2/B5/B8 |
|
|
GSM: 850/900/1800/1900MHz |
|
|
Battery |
Built-in 7.4V / 2000mAH |
|
External 7.4V / 6300mAH |
|
|
I/O ports |
HDMI x 1 |
|
USB 2.0 x 1、USB 3.0 x 3 |
|
|
DB9 RS232/485 × 1 |
|
|
RJ45 × 2 |
|
|
SIM x 1 |
|
|
SD x 1 |
|
|
POGO 5pin x 1 |
|
|
3.5mm earphone jack x 1 |
|
|
DC jack 19V 3.42A x 1 |
|
|
GPS |
GLONASS+QZSS+GPS |
| Sensor | Gyroscope、E-Compass |
|
Temperature |
Working:-10℃～+50℃ |
|
Storage: -20℃～+60℃ |
|
|
Dimension |
305mm*205mm*39 mm |
|
Net weight |
2850g |
|
Optional modules |
Fingerprint |
|
NFC 13.56MHz |
